High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production
  • High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop ProductionHigh-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production
  • High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop ProductionHigh-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production
  • High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop ProductionHigh-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production
  • High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop ProductionHigh-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production
  • High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop ProductionHigh-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production

High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production

The High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine is designed to provide reliable, stable, and precise welding performance for small workshop production, focusing on stainless steel, carbon steel, aluminum, and other thin metal materials. With an advanced air-cooled fiber laser system, it eliminates the need for external water cooling, reducing both maintenance and operational costs. This machine offers smooth weld seams, minimal heat distortion, and consistent welding quality. Lightweight, user-friendly, and compact, it is perfect for small-scale manufacturing, repair tasks, metal product assembly, and general fabrication, making it an ideal solution for businesses looking for efficient, high-quality welding in a small workshop environment.

Model:HW-AIR

Send Inquiry

Product Description

The HUAWEI LASER High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production is a durable and efficient Handheld Laser Welding Machine designed to meet the welding needs of small-scale workshops. Its air-cooled system ensures smooth operation with minimal maintenance, while the compact design makes it easy to handle in limited spaces. The HUAWEI LASER High-Quality 800W 1200W Air-Cooled Handheld Laser Welding Machine for Small Workshop Production provides clean weld seams, low heat distortion, and consistent output on materials like stainless steel, carbon steel, and aluminum. Ideal for daily welding tasks, it offers reliable performance for metalworking, fabrication, and repair applications in small workshop environments.


Attributes

Condition
New
Place of Origin
Liaoning, China
Weight
<39kg
Key Selling Points
Easy to Operate
Applicable Industries
Metal processing, Machinery manufacturing, Metal welding
Marketing Type
New product 2024
Core Components
Laser source
Brand Name
HUAWEI LASER
Single Pulse Energy
Other
Pules Width
Other
Focal Spot Diameter
Other
Dimensions

588mm*265mm*512mm

667mm*276mm*542mm

Laser Head Brand
MAX Photonics
Control System Brand
Max Photonics
Product Name
Air cooling laser welding machine
Application
Metal welding: weld carbon steel,stainless steel,aluminum,copper
Laser power supply
800w 1200w 1500w
Function
Handheld Welding
Key word
Air cooling, Portable, Handheld laser welding machine, High quality
Laser Source
Max Photonics
Welding gun
Max Photonics
Power Supply
AC220V 50HZ
Welding mode
Continuous welding
Cooling System

Air cooled


Product Specifications

Product model
HW-AIR 800
HW-AIR 1200
Weight
<29kg
<38kg
Volume
<0.08m
<0.1m°
Dimensions
588mm*265mm*512mm
667mm*276mm*542mm
Welding gun weight
0.68kg
0.68kg
Working mode
Continuous/Pulse
Continuous/Pulse
Laser swing
0-4mm
0-4mm
Input voltage
220VAC
220VAC
Power consumption
2500W
6000W



Welding Capability

Product Model

Welding Material

Stainless Steel
Carbon Steel
Galvanized Sheet
Aluminum
Brass
Copper
HW-AIR 1500

Single side penetration

4.5mm
4.5mm
4.0mm
3.0mm
3.0mm
1.5mm
HW-AIR 1200
Single side penetration
4.0mm
4.0mm
4.0mm
3.0mm
3.0mm
1.5mm
HW-AIR 800
Single side penetration
3.0mm
3.0mm
3.0mm
2.0mm
2.0mm
1.0mm


Welding materials


Welding samples



Quality Inspection Process


Exhibition


FAQ

1.Q: I don’t know which one is suitable for me ?

A :Just tell us below information

1) Materials and welding thickness: To match the right Power of laser generator for you.

2) Business industries: We sell a lot and give advice on this business line.

2.Q: When I got this machine, but I don’t know how to use it. What should I do?

 A: We will send training video and English manual with the machine in time. If you still have some doubts, we can talk by telephone or Whatsapp.

3.Q: How to install and run the machine?

A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. 95% customers can learn by themselves.

4.Q: How can I do if the machine goes wrong?

A: If confronted with such problems, Non-professionals should not repair the machine,please contact us ASAP. We will response within 24 hours as quick as we can to solve it for you.
